Differences from Apache StateFun¶
Apache Stateful Functions 3.4.0 (October 2024) is the last upstream release, locked to Flink 1.16 and Java 11. StateFun Actors continues the project against the modern Flink line. Most user code keeps working unchanged; the differences are at the runtime, dependency, and deployment layer.
At a glance¶
| Apache StateFun 3.4.0 | StateFun Actors KZM-3.4 | |
|---|---|---|
| Flink runtime | 1.16.2 | 2.2.1 |
| Java baseline | 11 | 21 |
| Maven group | org.apache.flink |
io.github.kzmlabs.flinkstatefun |
| Kinesis I/O | Built for Flink 1.x Kinesis source | Restored on Flink 2.x's KinesisStreamsSource/KinesisStreamsSink |
| Kafka record headers | Not supported | End-to-end round-trip — Message#headers() on ingress, egress builder on write, opt-in per topic |
| Active CI | Inactive after 3.4.0 | Ongoing — Dependabot, CodeQL, Scorecard, Trivy |
| K8s deployment | Examples in docs | K8s-native E2E gate via Flink Operator + LocalStack |
| Docker image | apache/flink-statefun:3.4.0 (Flink 1.16) |
ghcr.io/kzmlabs/flink-statefun:3.4.0-KZM-3.4 (Flink 2.2) |
| Test framework | JUnit 4 | JUnit Jupiter (6.x) |
| Release cadence | Dormant | Active (Maven Central + GHCR) |
Each fork-side decision has a record explaining its context and consequences: see the decision log. The most relevant per row: fork rationale ADR-0001, Kafka connector migration ADR-0002, Kinesis restoration ADR-0003, E2E gate ADR-0004, record headers ADR-0005.
Migrating user code¶
Most code is binary-compatible. The minimum change is the Maven coordinate:
<dependency>
- <groupId>org.apache.flink</groupId>
+ <groupId>io.github.kzmlabs.flinkstatefun</groupId>
<artifactId>statefun-sdk-java</artifactId>
- <version>3.4.0</version>
+ <version>3.4.0-KZM-3.4</version>
</dependency>
Function code, module.yaml, ingress/egress definitions, StatefulFunction implementations, the Context and Message API, and the HTTP request-reply wire format are unchanged.
Use the BOM
Importing statefun-bom removes individual version pins and keeps the module set + Flink + Java + Protobuf aligned. See the install guide.
Migrating runtime / deployment¶
If you deploy via Docker images or the Flink Operator, the runtime image was rebased on Flink 2.2. Three things to update:
1. Flink configuration keys¶
Flink 2.x renamed several keys. Update your module.yaml / Operator config:
| Old (Flink 1.x) | New (Flink 2.x) |
|---|---|
state.backend |
state.backend.type |
high-availability |
high-availability.type |
restart-strategy |
restart-strategy.type |
Flink 2.x silently ignores the short forms, so the symptom is "the cluster comes up but with default values."
2. Restart strategy¶
Flink 2.x's restart strategy keys use the restart-strategy.* prefix with an explicit .type:
flinkConfiguration:
restart-strategy.type: fixed-delay
restart-strategy.fixed-delay.attempts: 3
restart-strategy.fixed-delay.delay: 10s
Do not add an execution. prefix to these keys. Flink 2.x silently ignores
execution.restart-strategy.* and falls back to the default exponential-delay strategy
with unlimited restart attempts, which turns any poison-pill record into an infinite
restart loop instead of a terminal job failure.
3. Kinesis routing (if you use Kinesis I/O)¶
Flink 2.x's KinesisStreamsSource invokes KinesisDeserializationSchema.deserialize(record, stream, shardId, collector) with the stream ARN as the stream argument (Flink 1.x passed the short name).
The Kzmlabs SDK handles this transparently when you use RoutableKinesisIngressSpec. Custom deserializers must be updated to expect the ARN.
See the Kinesis I/O guide for the full Flink 2.x configuration model.
What is not different¶
- The function-as-actor programming model
- The
module.yamlschema (with the small Kinesis routing change noted above) - The HTTP request-reply wire protocol — interoperable with the upstream Apache StateFun Python/JS/Go SDKs
- State backend semantics (RocksDB, exactly-once via Flink checkpointing)
- Ingress/egress declarations for Kafka
Why this continuation exists¶
Upstream Apache StateFun has not received releases since October 2024. As Flink 2.x ships and JDK 11 leaves the active LTS support window, downstream users are left choosing between staying on an old Flink line or vendoring their own runtime patches. StateFun Actors is the public, actively maintained continuation — same code, modern dependencies, no vendor lock-in.
Next steps¶
- Install — Maven coordinates, BOM, version matrix.
- Quickstart — verify the migration with a five-minute round-trip.
- Kinesis I/O — Flink 2.x source/sink specifics (the most material difference).
- Kubernetes deployment — Flink 2.x Operator configuration.
